12 August 2015

Parts Washer for Jet Engine Overhaul – Case Study 20901

by bettereng1neer1ng / No Comments

Background The customer is a major re-builder of jet engines. They work in conjunction with the leading jet engine manufacturers. Parts Washing Problem The customer needed to replace an older jet washer that could not achieve the required cleanliness levels. The major problem was rinse water contamination. The parts held a lot of wash water […]

Read More

12 August 2015

RTO System for Helicopter Gear Boxes – Case Study 21319

by bettereng1neer1ng / No Comments

Background: This company manufactures a wide range of civil and military helicopters. Parts Cleaning Problem: They needed to clean gear boxes to the highest level. The System/Solution: This RTO-R-6000-PCS washer rotates the parts around a horizontal axis as they are being sprayed to flush out complex passages.  A dolly transports the parts in and out of the spray chamber.  This […]

Read More

12 August 2015

Aircraft Wheels & Brakes Powder Coating – Case Study 20708

by bettereng1neer1ng / No Comments

Background: This company is a leading supplier of aircraft wheels and brakes and related hydraulic products. Parts Cleaning Problem: This plant needed to clean and coat a variety of parts prior to paint (powder coating.) The steel parts needed to be iron phosphate coated.  The aluminum parts needed a Chromium III conversion coating. The System/Solution: […]

Read More

12 August 2015

Ultrasonic Washer for Jet Engine Fuel Pumps – Case Study 20185

by bettereng1neer1ng / No Comments

Background: This company is a leading supplier of aerospace components such as propulsion engines, engine controls, landing gear, etc.  In addition to manufacturing new components, they offer repair and rebuilding services. Parts Cleaning Problem: The application is rebuilding jet engine fuel pumps.  In terms of cleaning, this is one of the most difficult and challenging […]

Read More

12 August 2015

Sanitization Parts Washer – Case Study 21154

by bettereng1neer1ng / No Comments

Background At cosmetic companies, the filling machines have to be torn down and meticulously cleaned on a regular basis. This company has always hand cleaned their components using a team of workers. They were ready for a change. Parts Cleaning Problem The challenges included: a) cleaning off tenacious substances such as water -proof mascara; b) […]

Read More

12 August 2015

Cosmetic Pails Drums Parts Cleaning – Case Study 21155

by bettereng1neer1ng / No Comments

Background At cosmetic companies, the make-up constituents are stored in plastic pails and drums. These need to be cleaned after each use. This company cleaned the containers manually using a hand-held a pressure washer. The result was a mess in more ways than one. Parts Cleaning Problem Design a conveyor washer that could clean 5 […]

Read More

12 August 2015

Parts Cleaning System for Gas Cylinders – Case Study 21734

by bettereng1neer1ng / No Comments

Passivate Gas Cylinders This extraordinary machine cleans/ passivates gas cylinders inside and out. The system has six (6) individual cleaning chambers, each with a powered door and automatic valves to control flows from 3 tanks and air blow-off. The parts are loaded and unloaded with a robot. A top pneumatic device secures the part before […]

Read More

12 August 2015

Turntable Washer for Landing Gear – Case Study 1079

by bettereng1neer1ng / No Comments

Background This company has manufactured and serviced aircraft components for over 55 years.  Today they employ 20,000 people at 100 facilities in 16 countries.  They manufacture and service landing gear, wheel and brake assemblies, actuator systems, etc. Parts Cleaning Problem At their landing gear service centers, the customer needed batch loaded cleaning systems that can […]

Read More

12 August 2015

High Pressure Turbine (HPT) Blades Washer – Case Study 1000

by bettereng1neer1ng / No Comments

Background Hundreds of “Fins” surround the center “Rotor” section of Jet Engines. These fins are actually high pressure turbine (HPT) blades which are very complex. The surface of the part is peppered with tiny EDM holes which lead to a central cavity and larger “root holes” in the rectangular end. Parts Cleaning Problem These blades […]

Read More

12 August 2015

Spray Washer for Jet Engine Rotors – Case Study 1007

by bettereng1neer1ng / No Comments

Background This complex rotor part stands about 7 ft. tall, has a 40” diameter at its widest point, and weighs 1,000 lbs. The part has several rows of “HPT BLADES” and is covered with tiny holes. Parts Cleaning Problem First, this tall, 1,000 lb. part had to be fixtured so that the blades and other […]

Read More
