3 October 2016

Parts Cleaning Small Weapons Frames

by bettereng1neer1ng / No Comments

This C-24 loop conveyor washer is designed to clean trays of gun parts. The oval conveyor allows one operator to easily load and unload the trays from one vantage point. The sequence is as follows: 1) place a tray on gravity rollers and slide it onto the demagnetizing unit; 2) tray is then powered through […]

Read More

3 October 2016

Conveyor Washer for Large Metal Stampings

by bettereng1neer1ng / No Comments

This high speed (45 FPM) C-48-S15/ S15 conveyor washer removes heavy lubricant and black residue from hot rolled steel dome covers for pressure tanks.  A large portion of these parts are as large as 48″ dia. x 16″ high.  The conveyor washer is 50″ wide x 19″ high work envelope to accommodate the parts. This […]

Read More

3 October 2016

Return Conveyor Container Washer

by bettereng1neer1ng / No Comments

At cosmetic companies, the make-up constituents are stored in plastic pails and drums. These need to be cleaned after each use. This company cleaned the containers manually using a hand-held a pressure washer. The result was a mess in more ways than one. Better Engineering designed a conveyor washer that could clean 5 gallon pails […]

Read More

3 October 2016

Conveyor Washer to Clean Propane Tanks

by bettereng1neer1ng / No Comments

Recycle – Reuse! Empty, used propane tanks need to be thoroughly cleaned and prepared for recycling so they may be used again. This conveyor washer with a 36” wide belt has a dual track to hold two rows of propane tanks for increased productivity. Guide rails keep the tanks inline through wash, rinse, and dry […]

Read More

3 October 2016

Large Conveyor Washer 48″ Wide, 36″ IVC

by bettereng1neer1ng / No Comments

Conveyor washer with 48″ wide belt and 36″ inside vertical clearance used in powertrain production assemblies. Belt withstands 100 lbs. per linear foot. The 3-stage, wash/rinse/dry, system includes hinged access doors, adjustable air knives, an electronic eye to automatically stop parts at the unload end as well as a 20HP motor for the heated dry.

Read More

3 October 2016

Camshaft Crankshaft Engine Block Conveyor Washer

by bettereng1neer1ng / No Comments

Two (2) identical conveyor washers with custom fixturing – one designed to hold camshafts and crankshafts and the other to clean engine blocks.  These systems wash, rinse, and dry 120 parts or sets of parts every hour (the next step is assembly.) Electronic sensors and operator flag switches allow the conveyor to index to the […]

Read More

3 October 2016

Mini Conveyor Washer C-6

by bettereng1neer1ng / No Comments

Compact conveyor washer designed to fit in customer’s existing work cell (between a knurling machine and a induction heating unit). The customer’s pick and place unit automatically places the spline shafts onto the washer’s conveyor. The parts get washed , blown-off and then slide down a chute into the customer’s vibratory conveyor.

Read More

3 October 2016

Belt Washers for Stampings

by bettereng1neer1ng / No Comments

These C-14 conveyor washers clean metal stampings at high speed.  A top hold-down belt lays on the parts to keep them from blowing off the carrier belt. The belt washers are stainless steel, portable, and have wash, rinse, and dry stages.

Read More

3 October 2016

Conveyor Washer for Automotive Parts Cleaning

by bettereng1neer1ng / No Comments

This Cyberjet C-14 pick-and-place washer has a 360-loop table top conveyor belt. Camshafts are robotically placed on special fixtures.  The length of the part is in direction of travel; working width is only 6″. The fixture is designed for tight turns around the loop. The washer discharges to a position where a robot picks up a […]

Read More

3 October 2016

Conveyor Tote Washer

by bettereng1neer1ng / No Comments

This C-42 conveyor washer cleans and sanitizes medical waste containers.  The containers get dumped, washed in the C-42 and then get re-distributed to hospitals and medical facilities.  The C-42 has three stages: wash, rinse/sanitize (+180° F) and dry.   The work envelop is 42″ wide x 40″ high. This system is all stainless steel, the […]

Read More
